Class 10 Science Chapter 13 Board Questions

Class 10 Science Chapter 13 Board Questions of Magnetic Effects of Electric Current. These are the collection of previous years questions with solutions and answers. Board questions includes all the important questions from last ten years CBSE Board Exams Papers and all the questions of last 5 years’ questions. Questions are divided into sets of 5 questions. Segregation is made according to 1 mark, 2 marks, 3 marks and 5 marks questions. All the answers are according to the questions. For example, 1 mark questions in one word or one sentence, 2 two marks or 3 marks questions are answered point wise and long questions of 5 marks with complete description.

These questions provide a brief idea about the questions which are asked in CBSE Board exams and help the students in the preparation of final exams.

Page Contents

Class 10 Science Chapter 13 Board Questions for Exams

Class: 10Science
Chapter: 13Board Questions with Answers

Class 10 Science Chapter 13 Board Questions for Practice

Class 10 Science Chapter 13 Board Questions with answers for exams practice in 2020-2021. This page contains all the questions asked in CBSE board examination in last 10 years. We have included only important questions from last 10 years but all the questions from last 5 years. Answers of all the questions are taken from NCERT Textbooks only.

10th Science Chapter 13 Board Questions Set – 1 (1 Mark)

Name the type of current: (a) Used in household supply (b) given by a cell [CBSE 2012]

(a) Alternating current.
(b) Direct current.

Give one application of electromagnet induction. [CBSE 2012]

Electric generator.

Name the physical quantities which are indicates by the direction of thumb and forefinger in the Fleming’s right hand rule? [CBSE 2012]

In Fleming’s right hand rule
Thumb indicates- direction of motion of the conductor.
Forefinger- direction of magnetic field.

Name any two application which are based on the application of heating effect of electric current. [CBSE 2009]

Room heater and geyser.

What constitutes the field of a magnet? [CBSE 2006]

The region surround a magnet where the force of attraction or repulsion by the magnet can be detected constitutes the magnetic field and is represented by magnetic field lines.

10th Science Chapter 13 Board Questions Set – 2 (1 Mark)

How can you show that magnetic field produced by a given electric current in wire decreases as the distance from the wire increases? [CBSE 2006]

This can be shown by continuous decreases in the deflection of magnetic compass needle as it continuously shifts away from the current carrying conductor.

How will you use a solenoid to magnetise a steel bar? [CBSE 2006]

When steel bar is kept inside a current carrying solenoid along its axis, steel bar can be magnetised.

Define magnetic field of a bar magnet? [CBSE 2006, 2010, 2014, 2015, 2016]

The magnetic field of a bar magnet is the region around the magnet in which force due to magnet can be felt.

What is the direction of magnetic field at a given point? [CBSE 2012]

The direction in which N pole of a small compass needle placed at that point sets itself is the direction of magnetic field at that point.

Name the two factor that completely define a magnetic field at a point. [CBSE 2013]

The strength and direction of magnetic field at the given point.

Question: What are magnetic field lines? [CBSE 2010, 2011, 2012, 2015]
Answer: A magnetic field lines around a magnet is the path along which north pole of a magnetic compass needle points. A magnetic field line gives the direction of magnetic field at a point.




10th Science Chapter 13 Board Questions Set – 3 (1 Mark)

A what place of the magnet are magnified field lines closer? [CBSE 2007, 2013]

Near the poles of the magnet.

What is the direction of magnetic field lines of a magnet? [CBSE 2005, 2014]

From N pole toward S pole outside the magnet and from S pole towards N pole inside a magnet.

State the observation made by Oersted on the basis of his experiment with current carrying conductors? [CBSE 2012, 2013]

Every current carrying conductor has a magnetic field around it.

State the conclusion that can be drawn from the observation that a current-carrying wire deflects a magnetic needle placed near it? [CBSE 2012]

A magnetic field is produced around a current carrying conductor.

What is the shape of magnetic fields due to straight current carrying conductor? [CBSE 2010, 2014, 2013, 2015]

Magnetic field lines forms concentric circles around the conductor with conductor at the center.

10th Science Chapter 13 Board Questions Set – 4 (1 Mark)

How is the strength of magnetic field at a point near a wire related to the strength of the electric current flowing in the wire? [CBSE 2014]

Strength of magnetic field is directly proportional to the strength of current flowing in the wire.

How will the magnetic field around a straight current-carrying conductor be affected on increasing the current in the conductor? [CBSE 2012]

The strength of the magnetic field increases on increasing the current flowing through the conductor.

What happens to the magnetic field lines due to current to a current-carrying conductor when the current is reserved? [CBSE 2010, 2011, 2012]

The direction of the magnetic field gets reserved on changing the direction of flow of current in a straight conductor.

Where will the value of magnetic field maximum due to current carrying circular conductor? [CBSE 2006]

At the center of current carrying circular loop.

Mention the region of a current carrying solenoid where field lines are parallel straight lines. [CBSE 2013]

Along the axis of solenoid.

Question: Under what condition is the force by a current carrying conductor placed in a magnetic field maximum? [CBSE 2009, 2012, 2016]
Answer: The force acting on a current carrying conductor placed in a magnetic field is maximum when the direction of current is at right angles to the direction of the magnetic field.




10th Science Chapter 13 Board Questions Set – 5 (1 Mark)

What is the shape of a current-carrying conductor whose magnetic field pattern resembles that of bar magnet? [CBSE 2011]

A solenoid coil.

When is the force experienced by a current carrying conductor placed in a magnetic field (i) maximum (ii) minimum [CBSE 2010, 2011]

The force experienced by a current carrying conductor placed in a magnetic field is (i) maximum when direction of current is at right angles to the direction of magnetic field, (ii) minimum (zero) when direction of current is parallel or antiparallel to the direction of magnetic field.

Why does a current carrying conductor experience a force when it is placed in a magnetic field? [CBSE 2011, 2015]

A current carrying conductor produces a magnetic field around it. This magnetic field interacts with the externally applied magnetic field and as a result the conductor experiences a force.

What is the function of a galvanometer in a circuit? [CBSE 2019]

A galvanometer is used to detect the flow of current, if any, in a circuit.

Define the term ‘induced current’? [CBSE 2009, 2012]

Electric current set up in a closed coil/circuit, whenever, magnetic field near it is changing, is called an induced current.

10th Science Chapter 13 Board Questions Set – 6 (1 Mark)

Write any one method to induce current in a coil? [CBSE 2014, 2016]

Whenever magnetic field around a coil is changed, a current is induced in the coil.

Name the physical quantities which are indicated by the direction of thumb and forefinger in the Fleming’s right-hand rule.[CBSE 2012]

Thumb indicate the direction of motion of the conductor and forefinger indicates the direction of magnetic field.

Give one application of electromagnetic induction. [CBSE 2010, 2012]

An electric generator.

How is the induced current in a secondary coil related to current in a primary coil? [CBSE 2009]

Magnitude of induced current in a secondary coil is directly proportional to the rate of change of current in a primary coil.

What type of current is given by a cell? [CBSE 2011, 2012, 2014, 2016]

Direct current (D.C.).

Question: What is electromagnetic induction? [CBSE 2010, 2011, 2012, 2014, 2016]
Answer: Electromagnetic induction is the phenomenon of producing induced current in a closed circuit (coil) by changing magnetic field near it or by moving the coil in the magnetic field.



10th Science Chapter 13 Board Questions Set – 7 (1 Mark)

What type of current is used in household supply? [CBSE 2011, 2012]

An alternating current (A.C.).

What is the frequency of A.C. being supplied in our homes? [CBSE 2010, 2013, 2015]

50 Hz.

An alternating electric current has a frequency of 50Hz. How many times does it change its direction in one second? [CBSE 2012]

Change its direction in one second
= 50 × 2
= 100 times.

Name one device which provides an alternating current. [CBSE 2012]

An electric generator.

Write one advantage of A.C. over D.C. [CBSE 2010, 2012]

Electric power in A.C. can be easily transmitted over long distances without much loss of energy.

10th Science Chapter 13 Board Questions Set – 8 (1 Mark)

What are the commonly used colours for insulation of live, neutral and earth wires used in domestic electric supply? [CBSE 2011, 2014]

Red for live wire insulation, black for neutral wire insulation and green for earth wire insulation.

Insulation cover of which colour is conventionally used for earth wire. [CBSE 2011, 2014]

Wire of green insulation cover is conventionally used for earth wire.

Why is an earth wire connected to metallic parts of appliances? [CBSE 2007, 2012, 2014]

When an earth wire is connected to metallic parts of appliances, any leakage of current to the metallic parts is safely conducted to the ground. Thus, severity of shock received by a person on touching the metallic part is very much reduced.

What potential difference is maintained between the live wire and neutral wire in our domestic electric supply circuit? [CBSE 2010, 2012, 2014, 2015]

The live wire.

To which wire do you connect fuse wire in a household circuit? [CBSE 2011, 2014]

With live wire.

Question: What is the function of fuse in the domestic electric circuit? [CBSE 2006, 2011, 2013]
Answer: A fuse (or fuse wire) is used to protect the electric circuit in case of short circuiting of circuit or in case of overloading of the circuit.

10th Science Chapter 13 Board Questions Set – 9 (1 Mark)

Name the device used to prevent damage to the electrical appliances and the domestic circuit due to over loading. [CBSE 2011, 2012]

Electric fuse.

Why do we connect earth wire in a house? Give two reasons. [CBSE 2011]

AS a safety measure for the user person. User will not get a severe electric shock even in case of leakage, if proper earth wire has been installed.

What is the advantage of the third wire of earth connection in domestic electric appliances? [CBSE 2006]

It provides a safety measure to the user person and saves him from a severe shock even when there is leakage of current.

What is short circuiting? [CBSE 2012]

Short circuiting means that the two wire, live and neutral of the domestic electric circuit have common in contact with each other.

What precautions should be taken to avoid the overloading of domestic electric circuits? [CBSE 2010, 2011, 2012]

(i) Too many electrical appliances should not be operated using a single socket.
(ii) Too many large power rating appliances should not be switched on at a time.

10th Science Chapter 13 Board Questions Set – 10 (2 Marks)

A compass needle is placed near current carrying wire state your observation for the following cases and give reason for the same in each case- (a) Magnitude of electric current in the wire is increased. (b) The compass needle is displaced away from the wire. [CBSE 2012]

(a) Observation: Deflection of needle increases
Reason: Magnetic field strength due to current carrying wire increases as current in wire increases.
(b) Observation: The deflection in the compass needle decreases as its displacement from the current carrying wire increases.
Reason: Strength of magnetic field reduces with the increase in the distance from the wire.

Insulation cover of which colour is conventionally for earth wire? Why is an earth wire connected to metallic connected to metallic part of appliances? [CBSE 2011]

For earth wire green or yellow colour insulation is used. It provides the low resistance conducting path for the current and maintains the potential of appliances body with that of the earth. So earth wire is used as safety measures.

Explain the role of fuse in series with any electrical appliance in the electric circuit. Why should a fuse with defined rating for an electric circuit not be placed by one with a larger rating? [CBSE 2011]

Role of fuse: It is a safety device connected in series with live wire or with any electrical appliances in an electric circuit. It stops the flow of unduly high electric current in the circuit by melting itself due to rise in temperature as per Joule’s law of heating High rating fuse wire has the larger capacity. So it will not stop the flow of any unduly high current. Therefore, electric devices cannot be protected from the possible damage.

The magnetic field associated with a current carrying straight conductor is in anticlockwise direction. If the conductor was held along the east west direction, what will be the direction of current through it? Name and state the rule applied to determine the direction of current. [CBSE 2011]

Direction of current- east to west is determine by Right hand thumb rule.
Right Hand Thumb Rule: If we hold a current carrying conductor by right hand in such a way that the stretch thumb is along the direction of current then the curly fingers around the conductor represents the direction of current then the curly fingers around the conductor represents the direction of field lines of magnetic field.

A coil of insulated wire is connected to a galvanometer. What would be seen if a bar magnet with its north pole towards one face of coil is (i) moved quickly towards it, (ii) moved quickly away from the coil and (iii) placed near its one face? Name the phenomena involved. [CBSE 2010]

(i) Deflection in the galvanometer needle will be more on right side.
(ii) Larger deflection in opposite direction as compared to the case (i) will be seen
(iii) No deflection.

Distinguish between a direct current and an alternating current. [CBSE 2012, 2013, 2014, 2015]
Direct Current (D.C.)Alternating Current (A.C.)
1. Direct current always flows in one direction only.1. Alternating current reverses its direction periodically.
2. The magnitude of current may or may not remain constant.2. Magnitude of current continuously changes with time.
3. Current obtained from a battery and D.C. generator is D.C.3. Current obtained from an A.C. generator and current in our domestic circuit are A.C.




10th Science Chapter 13 Board Questions Set – 11 (2 Marks)

Two coils A and B insulated wire are kept close to each other. Coil A is connected to a galvanometer while coil B is connected to a battery through a key. What would happen if (i) a current is passed through coil B by plugging the key and (ii) the current is stopped by removing the plug from the key? Explain your answer mentioning the name of the phenomena involved. [CBSE 2010]

In both the given case galvanometer shows momentary deflection but in opposite direction. IN coil A magnetic field lines [increases in case (i) and decreases in case (ii)] induces a potential difference across the coil A which set up induced electric current in coil A. It is shown by the deflection in the galvanometer. This is known as electromagnetic induction.

What is meant by the term frequency of an alternating current? What is the value in India? Why is alternating girl considered to be advantages over direct current for long range transmission of electric energy? [CBSE 2009]

Frequency of the Alternating current is equal to the number of cycles complete in one second. In India frequency of AC is 50 Hz. An alternating current is considered to be advantageous over direct current for long range transmission of electric energy because it can be transmitted over long distances to distinct places without much loss of electric power as compared to direct current.

What is electromagnet? [CBSE 2008]

The temporary magnet which retain its magnetism as long as the current passes through the coil wound around the piece of soft iron core.

What is meant by the term magnetic field? Why does a compass needle show deflection when brought near a bar magnet? [CBSE 2008]

Magnetic field: The region surrounding a magnet in which another magnet experience a force of attraction or repulsion is called magnetic field. Compass needle is a small magnet. When it is placed in a magnetic field of a bar magnet, it experiences magnetic force due to which it gets deflected.

Write one application of each of the following: (a) Right hand thumb rule (b) Fleming’s left hand rule (c) Fleming’s right hand rule [CBSE 2012]

(a) Right hand thumb rule is used to find the direction of magnetic field in a coil of wire and the electric current in a straight conductor.
(b)Fleming’s left hand rule is used to find the direction of force exerted on a current carrying conductor in a magnetic field as in electric motor.
(c) Fleming’s right hand rule is used to find the direction of induced current in a closed circuit in changing magnetic field as in electric generator.

Download NCERT Books and Online as well as Offline Apps 2020-21 based on new CBSE Syllabus. Ask your doubts related to NIOS or CBSE Board and share your knowledge with your friends and other users through Discussion Forum.

10th Science Chapter 13 Board Questions Set – 12 (3 Marks)

What is short circuiting? State one factor/condition that can lead to it. Name a device in the household that acts as a safety measure for it. State the principal of its working. [CBSE 2012]

Short circuiting: When electric current offers very low resistance to the flow of current through it, the current increases heavily and the circuit is said to be ort circuited. It occurs when live wire touches the neutral wire. This happen due to damage in insulation of the power lines.
Safety measures device: Fuse.
Working principal of fuse: It works on heating effect of electric current or Joules law of heating.
According to this law the heat produced in a resistor is directly proportional to the
(i) square of current for a given resistance.
(ii) resistance for a given current and
(iii) time for which current flows through the resistor.

State one main difference between AC and DC. Why AC is preferred over DC for long range transmission of electric power? Name the source each AC and DC. [CBSE 2012]

Difference between AC and DC The alternating current (AC) reverse its direction periodically whereas the direct current (DC) always flows in one direction AC is preferred over DC because it can be transmitted over long distance without much loss of energy.
DC source: Battery
AC source: AC generator

How will the magnetic field have produced at a point due to a current carrying circular coil change if we: (i) increase the current flowing through the coil? (ii) reverse direction of current through the coil? (iii) increases the number of turns in the coil? [CBSE 2011]

Magnetic field B at the current of the circular coil
(i) increases the current is increased B∝ I
(ii) reverses on reversing of current.
(iii) increases if the number of turns in the coil increases as field is directly proportional to the number of turns.

(a) Mention the factors on which direction of force experienced by a current carrying conductor placed in a magnetic field depend. (b) under what conditions is the force experienced by a current carrying conductor placed in a magnetic field maximum? (c) proton beam is moving along the direction of a magnetic field. What force is acting on proton beam? [CBSE 2011]

(a) The direction of force experienced by the current carrying conductor depends on
(i) direction of current and
(ii) direction of magnetic field
(b) When the direction of current is at to the direction of magnetic field the force is maximum.
(c) No forced is experienced by the proton beam As proton beam moving along the direction of magnetic field.

What are magnetic field lines? how is the direction of a magnetic field at a point determined? Mention two important properties of magnetic field lines. [CBSE 2011, 2012]

Magnetic field lines are used to represent a magnetic field. A field line is the path along which the north pole of a small compass tends to move. The direction of the magnetic field at a point is given by the direction in which north pole of compass placed at that point would take.
Two properties of magnetic field lines are as follows:
(i) In air field lines start from N pole and end at S pole.
(ii) No two magnetic field lines can ever intersect at any one point.

Main differences between an electric motor and a generator
Electric MotorElectric Generator
1. Electric motor is a device which converts electrical energy into mechanical energy.1. Electric generator is a device which converts mechanical energy into electrical energy.
2. It works on the principle of Fleming’s left hand rule.2. It works on the principle of Fleming’s right hand rule.



10th Science Chapter 13 Board Questions Set – 13 (3 Marks)
(a) Describe an activity to draw magnetic field lines outside a magnetic form one pole to another pole. (b) What does the degree of closeness of field lines represented? [CBSE 2012, 2014, 2016]

(a) Take a bar magnet and place it on a sheet of white paper fixed on a drawing sheet. Mark the boundary of magnet. Take a small compromise and place it near the north pole of the magnet. Mark the position of two ends of compass needle. Move the needle to a new position so that its south pole occupies the position previously occupied by its north pole. In this way proceed step by step till we reach the south pole of magnet. Join the points marked on the paper by a smooth curve. This curve represents a magnetic field line.
(b) The degree of closeness of magnetic field lines signifies the strength of magnetic field.

Describe an activity to demonstrate the presence of magnetic field around a current carrying straight conductor. [CBSE 2016]

Take a long straight thick copper wire and insert it through the center of a plane cardboard. Cardboard is fixed so that it is perfectly horizontal and the thick wire is in vertical direction.
Prepare an electric circuit consisting of a battery a variable resistance an ammeter and a plug key. Connect the copper wire in the circuit between the point X and Y. Sprinkle some iron-fillings uniformly on the cardboard. Put the plug in the key K so that a current flow in the circuit. Gently tap the cardboard using a finger. We observe that the iron filings align themselves forming a pattern of concentric circles around the copper wire. These concentric circle represent the magnetic field lines. Direction of field lines is determined by the uses of a compass needle. If current is flowing vertically downward then the magnetic field lines are along clockwise direction. If current is flowing vertically upward then the field lines are along anticlockwise direction.

Describe an activity to show the magnetic field lines formed by a current carrying circular coil. [CBSE 2010, 2013, 2015, 2016]

Take a rectangular cardboard sheet. Make two hole in it at a suitable distance. Insert a circular coil having large number of turns of enameled copper wire passing through these holes so that the coil is normal to the plane to the cardboard. Complete the electric circuit by joining ends of the coil with a battery and a key K. Sprinkle iron-fillings uniformly on the cardboard. Plug the key and gently tap the cardboard. The iron filings arrange themselves along the magnetic field lines. The pattern of iron filings gives the magnetic field lines. The pattern of iron filings gives the magnetic field lines due to current carrying circular coil.

How will the magnetic field produced in a current carrying circular coil change if we increase the (i) value of current, (ii) distance from the coil, (iii) number of turn of the coil? [CBSE 2011]

(i) The magnetic field produced in a current carrying circular coil increases on increasing the value of current.
(ii) On increasing the distance from the coil the magnetic field strength decreases.
(iii) The value of magnetic field increases on increasing the number of turn of the circular coil.

What is a solenoid? Write three important features of the management field obtained. [CBSE 2010, 2011, 2012, 2014, 2015, 2016]

A solenoid is a coil of large number of circular turns of wire wrapped in the shape of a cylinder. On passing electric current a magnetic field is developed. Magnetic field lines are drawn below. The field is along the axis of solenoid such that one end of solenoid behaves as north pole and the other south pole. Thus field of a solenoid is similar to that of a bar magnet
Important features of magnetic field due to a current carrying solenoid are:
(i) Magnetic field lines inside the solenoid are nearly straight and parallel to its axis. It shows that magnetic field inside a solenoid is uniform.
(ii) Magnetic field of solenoid is identical to that due to a bar magnet with one end of solenoid behaving as a north pole and other end as a south pole.
(iii) A current carrying solenoid exhibits the detective and attractive properties of a bar magnet.

Question: Write the rule which determines the direction of magnetic field developed around a current carrying straight conductor. [CBSE 2010, 2011, 2012, 2014, 2015]
Answer: The direction magnetic field around a straight current carrying conductor is given by right hand thumb rule. According to the rule, imagine holding the current carrying straight conductor in your right hand such that the thumb points towards the direction of current. Then the fingers of right hand wrap around the conductor in the direction of the magnetic field.

10th Science Chapter 13 Board Questions Set – 14 (3 Marks)
What is a solenoid? Mention two ways to increases the strength of the magnetic field of a solenoid. [CBSE 2008, 2010, 2012, 2013, 2014, 2016]

A solenoid is a coil of large number of circular turns of wire wrapped in the shape of a cylinder. On passing electric current a magnetic field is developed. Magnetic field lines are drawn below. The field is along the axis of solenoid such that one end of solenoid behaves as north pole and the other south pole. Thus field of a solenoid is similar to that of a bar magnet.
The strength of magnetic field of a solenoid can be increased by (i) increasing the current flowing through solenoid coil and (ii) increasing the number of turns per unit length of the solenoid coil.

What are permanent magnet and electromagnet? Give two uses of each. [CBSE 2010, 2011]

Magnets having constant magnetic field around them (e.g. a bar magnet) are called permanent magnets. Permanent magnets are used in electric generators, speakers, refrigerator door etc.
Material behaving as magnet only when a current is passed through a coil wound around the material are called electromagnet. Electromagnets are used in electric bell, transformer, electric cranes etc.

(a) What is an electromagnet? (b) State two ways by which the strength of an electromagnet can be increased. [CBSE 2010, 2011, 2012]

(a) An electromagnet is a rod of magnetic material (say soft iron) placed inside a solenoid coil. On passing current in solenoid coil, iron rod begins to behave as a magnet. ON stopping the current flow, magnetization of iron is lost. Thus, a soft iron piece behaves as an electromagnet.
(b) The strength of an electromagnet can be increased by
(i) Increasing the number of turn of windings of the solenoid coil wrapped around the electromagnet, or
(ii) Increasing the amount of electric current flowing through the coil.

State important characteristics of magnetic force experienced by charge moving in a magnetic field (or a current carrying conductor placed in a magnetic field). [CBSE 2014]

Important characteristics of magnetic force are as given below:
(i) Magnetic force acts only on moving charges (or flowing current) and does not act as stationary charges.
(ii) Force acts on moving charge when its motion is not parallel to the direction of magnetic field. Similarly, magnetic force acts when current carrying conductor is in any direction other than the direction of magnetic field.
(iii) Magnitude of magnetic force is maximum when current carrying conductor is set perpendicular to magnetic field or when charge is moving at right angle to magnetic field.
(iv) The direction of force F is given by Fleming’s left hand rule.
(v) The magnitude of magnetic force depends upon (a) the amount of current I, (b) the magnetic field B and (c) the length of the conductor l. On increasing anyone or all of these factors force increases proportionately.

A metallic conductor is suspended perpendicular to the magnetic field of a horse shoe magnet. The conductor gets displaced towards left when a current is passed through it. What will happen to the displacement of the conductor if the: (i) current through it is increased? (ii) horse-shoe magnet is replaced by another stronger horse-shoe magnet? (iii) direction of current through it is reversed? [CBSE 2011, 2012, 2015]

(i) On increasing the current flowing through metallic conductor, the force experienced by it is proportionately increased because F∝ I.
(ii) On using a stronger horse-shoe magnet the magnetic force increases because F∝ B.
(iii) On reversing the direction of current the direction of force is reversed and conductor is displaced towards right instead of left direction.

Question: Why is alternating current preferred over direct current? List any three reasons. [CBSE 2011, 2012]
Answer: An alternating current is preferred over direct current due to the following reasons:
(i) A.C. generator is simpler and easy to operate and maintain.
(ii) A.C. voltage can be stepped up or stepped down as per convenience.
(iii) A.C. can be easily transmitted over long distances.

10th Science Chapter 13 Board Questions Set – 15 (3 Marks)
(a) List four factors on which the magnitude of magnetic force acting on a moving charge in a magnetic field depend. (b) How will a fine beam of electrons streaming in west to east direction be affected by a magnetic field directed vertically upwards? [CBSE 2014, 2016]

(a) Magnitude of magnetic force acting on a moving charge in a magnetic field depends on (i) The magnitude of charge (ii)speed of moving charge (iii) strength of magnetic field (iv) the angle between the direction of motion of charge and the direction of magnetic field.
(b) The electron streaming from west to east is equivalent to a current from east to west. The magnetic field B is vertically upwards and shown by cross marks (x). Hence, in accordance with Fleming’s left hand rule, the electron will experience a force in north direction and deflected in that direction.

A coil of insulated copper wire is connected to a galvanometer. What would happen if a strong bar magnet is: (a) pushed into the coil? (b) withdrawn from inside the coil? (c) held stationary inside the coil? Give justification for each observations. [CBSE 2011, 2012, 2014, 2015, 2019]

(a) When a bar magnet is pushed into the coil of insulated copper wire connected to a galvanometer, an induced current is set up in the coil. As a result, galvanometer gives a deflection (say towards left).
(b)When the bar magnet is withdrawn from inside the coil, again an induced current is set up in the coil. However now direction of induced current is opposite to that in earlier case. Hence, deflection in galvanometer is in reverse direction (say towards right).
(c) If the bar magnet is held stationary inside the coil, then there is no induced current in the coil. As a result, galvanometer does not show any deflection.

Describe an activity to explain how a moving magnet can be used to generate electric current in a coil. [CBSE 2012, 2014, 2015]

Take a coil AB of insulated copper wire having a number of turns. Connect the ends of coil to a sensitive galvanometer G. Now take a bar magnet NS and rapidly bring the magnet towards the end B of coil. The galvanometer gives momentary deflection in one direction. Now take the magnet away from the coil, the galvanometer again gives momentary deflection but in the opposite direction. It clearly shows that motion of magnet induces, a current in the coil.
Again keep the magnet fixed and gently move the coil AB either towards the magnet or away from the magnet. We get deflection in galvanometer even now. Thus, an induced current is produced in a coil whenever there is relative motion between the coil and the magnet. This phenomenon is known as the electromagnetic induction.

A coil made of insulated copper wire is connected to a galvanometer. What will happen to the deflection of the galvanometer if a bar magnet is pushed into the coil and then pulled out of it? Give reason for your answer and name the phenomenon involved. [CBSE 2010, 2011, 2012]

Take a coil AB of insulated copper wire having a number of turns. Connect the ends of coil to a sensitive galvanometer G. Now take a bar magnet NS and rapidly bring the magnet towards the end B of coil. The galvanometer gives momentary deflection in one direction. Now take the magnet away from the coil, the galvanometer again gives momentary deflection but in the opposite direction. It clearly shows that motion of magnet induces, a current in the coil.
Again keep the magnet fixed and gently move the coil AB either towards the magnet or away from the magnet. We get deflection in galvanometer even now. Thus, an induced current is produced in a coil whenever there is relative motion between the coil and the magnet. This phenomenon is known as the electromagnetic induction.

Describe an experiment to show that a change in current flowing through a coil induces an electric current in a neighboring coil. [CBSE 2011, 2012]

Take two different coils (say P and Q) of insulated copper wire having large number of turns. Insert the two coils over a non-conducting cylindrical thick paper roll.
Connect a battery and a plug key K in series of coil-1 (P). With coil-2 (Q) connect a sensitive galvanometer G. Now put the plug in key K. The galvanometer joined with coil-2 (Q) also gives a momentary deflection and then the pointer quickly returns to its mean position.
Now remove the plug from key K. The galvanometer in coil-2 (Q) again gives a momentary deflection but in the reverse direction.
Moreover, we observe that as soon as current in coil I (P) becomes either steady or zero, there is no deflection in galvanometer.
From the above experiment we conclude that an induced is produced in coil-2 (Q) on account of electromagnetic induction whenever current in coil-1 (P) is changing.

10th Science Chapter 13 Board Questions Set – 16 (3 Marks)
Two circles coils P and Q are kept close to each other, of which coil P carries a current. What will you observe in the galvanometer connected across the coil Q. (a) if current in the coil P is changed? (b) if both the coils are moved in the same direction with the same speed? Give reason to justify your answer in each case. [CBSE 2011, 2019]

(a) If current in the coil P is increased we get momentary deflection in galvanometer connected across the coil Q in one direction. However, if current in the coil P is decreased, the deflection in galvanometer is in opposite direction. Due to change of current in coil P, the magnetic field of coil Q also changes and so as induced current is set up in coil Q and the galvanometer shows a deflection.
(b) If both the coils P and Q are moved in the same direction with the same speed, the magnetic field of both the coils remain unchanged. Hence no induced current is set up in coil Q and there is no deflection in the galvanometer.

What is an electric fuse? Briefly describe its function. [CBSE 2010, 2011, 2012, 2013] Explain the use of electrical fuse. What type of fuse material is used for fuse wire and why? [CBSE 2013, 2014, 2016]

An electric fuse is device which is used ahead and in series of an electric circuit as a safety device to prevent the damage caused by short-circuiting or overloading of the circuit.
It is a small, thin wire of a material whose melting point is low. Generally, wire of tin or tin-lead alloy or thin-copper alloy is used as a fuse wire. If due to some fault electric circuit gets short-circuited, then a strong current begins to flow. Due to such strong flow of current the fuse wire is heated up and gets melted. As a result, the electric circuit is broken and current flow stops. Thus, possible damage to the circuit and appliances is avoided.

Describe four important features of domestic electric supply lines. [CBSE 2016]

Important features of domestic electric supply lines are as given below:
(i) Different circuits and different appliances in each circuit are connected in parallel.
(ii) Each appliances are provided with an independent on/off switch which is always joined to the live wire.
(iii) Two separate circuits are used, one of 15 A for appliances with higher power ratings and another of 5 A for bulbs, tubes, fans, etc.
(iv) Electric fuses of appropriate capacities are used ahead of each electric circuit as a safety measure. Moreover, proper earthing must be ensured.

A student fixes a sheet of white paper on a drawing board. He places a bar magnet in the center of it. He sprinkles some iron filings uniformly around the bar magnet. Then he taps the board gently. Now answer the following Questions: (i) What does the student observes? (ii) Why do iron filings arrange in such a pattern. (iii) What does the crowding of the iron filings at the ends of magnet indicate? [CBSE 2015]

(i) The student observes the magnetic field due to the given bar magnet.
(ii) There is the magnetic field around the given bar magnet. The iron filings experience force due to the magnetic field and thus align themselves along the magnetic field lines.
(iii) The crowding of the iron filing at the ends of the magnet indicate the position of the two magnetic poles N and S of given bar magnet.

(a) State and apply right hand thumb rule to mark the direction of the magnetic field lines. (b) How will the strength of the magnetic field changes when the point where magnetic field is to be determined is removed away from straight conductor? Given reason to justify your answer. [CBSE 2019]

(a) The direction magnetic field around a straight current carrying conductor is given by right hand thumb rule. According to the rule, imagine holding the current carrying straight conductor in your right hand such that the thumb points towards the direction of current. Then the fingers of right hand wrap around the conductor in the direction of the magnetic field.
(b) The strength of magnetic field due to current carrying straight conductor is inversely proportional to the normal distance between the conductor and the point where magnetic field is to be determined. So as the point as moved away the strength of the magnetic field goes on decreasing.

Question: One of the major causes of fire in office buildings is short circuiting. List three reasons which may lead to short circulating. How can it be prevented? [CBSE 2016]
Answer: Three possible reasons of short circuiting of an electrical circuit are as follow:
(i) The insulation of electrical wiring is damaged.
(ii) The electrical appliance used in the circuit is defective.
(iii) An appliance of higher power rating is being run on an electrical line of lower power rating.
Short circuiting can be prevented by the use of electrical fuse of appropriate capacity.



10th Science Chapter 13 Board Questions Set – 17 (5 Marks)
(a) What is a solenoid? (b) What does the pattern of field lines inside the solenoid indicate? How can this field be utilised to magnetise a piece of soft iron? [CBSE 2011, 2009, 2013, 2013, 2014, 2015]

(a) A solenoid is a coil of large number of circular turns of wire wrapped in the shape of a cylinder. On passing electric current a magnetic field is developed. Magnetic field lines are drawn below. The field is along the axis of solenoid such that one end of solenoid behaves as north pole and the other south pole. Thus field of a solenoid is similar to that of a bar magnet
Important features of magnetic field due to a current carrying solenoid are:
(i) Magnetic field lines inside the solenoid are nearly straight and parallel to its axis. It shows that magnetic field inside a solenoid is uniform.
(ii) Magnetic field of solenoid is identical to that due to a bar magnet with one end of solenoid behaving as a north pole and other end as a south pole.
(iii) A current carrying solenoid exhibits the detective and attractive properties of a bar magnet.
(b) The pattern of filed lines inside the solenoid indicate that solenoid is now behaving as a bar magnet with one end behaving as the north pole and the other end as the south pole of the magnet. If a piece of soft iron is placed inside the solenoid and a current is passed through the solenoid coil the iron piece is magnetised and begins to behave as an electromagnet.

(a) State Flemings left hand rule. (b) Write the principal of working of an electric motor. (c) Explain the function of the following part of an electric motor: (i) Armature (ii) Brushes (iii) Split ring. [2016]

(a) Fleming’s left hand rule states that stretch the forefinger the central finger and the thumb of your left hand in mutually perpendicular to each other. If the forefinger shows the direction of the magnetic field and the central finger that of the current, then the thumb will point toward the direction of motion of conductor.
(b) An electric motor works on the principal that a coil carrying current when placed in a uniform magnetic field experience a force whose direction is given by Flemings left hand rule. As a result the coil start rotating about its own axis.
(c) Function of various parts of motor is given below
(i) Armature coil carries current. As a result, two long arms of armature coil experience equal force in mutually opposite direction and under their influence the coil begins to rotate.
(ii) Brushes draw current from split rings and supply it to the coil.
(iii) Split rings draws current from the battery. However, split rings change their contacts with brushes after every half rotation. As a result, current supplied to the armature coil through brushes changes its direction after every half rotation.

(a) State the rule you would use to find the force acting on a current carrying conductor placed in a magnetic field. (b) Name two devises based on interaction between magnetic field and current carrying conductor. [CBSE 2013]

(a) Fleming’s left hand rule states that stretch the forefinger the central finger and the thumb of your left hand in mutually perpendicular to each other. If the forefinger shows the direction of the magnetic field and the central finger that of the current, then the thumb will point toward the direction of motion of conductor.
(b) Electric fan, refrigerator, electric mixer, washing machine etc., make use of interaction between magnetic field and a current carrying conductor.

(i) What is the function of earth wire in electrical instruments? (ii) Explain what is short circuiting an electric supply. (iii) What is the usual current rating of fuse wire in the line to feed. (a) lights and fans? (b) appliances of 2kW or more power? [CBSE 2011, 2014, 2015]

(i) The earth wire function as a safety measure for electric appliances having a metallic body. Due to use of earth wire the user does not get a severe shock even when there is some leakage of current in metallic body of appliances.
(ii) Short circuiting of an electric supply means direct contact of the live wire and the neutral wire of supply line without any load in between. Short circuiting occurs either due to some fault in electric circuit or due to damage to insulation of live wire.
(iii) (a) Usual current rating of the fuse wire in the line to feed lights and fans is 5A.
(b) Usual current rating of the fuse wire in the line to feed appliances of 2kW or more power is 15 A.
