Class 7 Science Chapter 11 MCQ

Concave mirror and convex lens can only from enlarge image of an object. As convex mirror and concave lens always from a diminished image of an object.

When an object is placed at a distance between focal length and twice the focal length of a concave mirror, then the image formed by concave mirror is real, inverted and larger than object. When an object is placed close to concave mirror (at less than focal length), the image formed by a concave mirror is virtual, erect and larger than the object.

Remember, that whether an object is placed at a large distance or it is close to convex mirror, a convex mirror always forms an image which is virtual, erect and smaller than the object. Changing the position of object in front of a convex mirror only changes the size of image. But in every case, the image remains smaller than the object. (Note: A plane mirror and a convex mirror always forms a virtual and erect image of an object.)

We know that concave mirrors are used as shaving mirrors to see a large image of the face. Concave mirrors are used by dentist to see the large images of teeth patients. Concave mirrors are used as reflectors in torches, headlights of vehicles. Doctors use concave mirror as reflector to produce a parallel beam of light for examining the body parts such as eyes, ears, nose etc. Concave mirrors are also used in dish antenna to receive TV signals from satellites. Convex mirrors are used as rear-view mirrors or side view mirrors in vehicles (such as cars, scooters, buses etc.) to see the traffic at the rear side or back side on the road.

Here, all the statements are correct. Hence your answer will be option [D].

The objects having polished, shining surfaces reflect more light than objects having unpolished dull surfaces.

We can see the objects around us because they reflect light received from a non-luminous object. We can see a table lying in a room because it reflects light falling on it in all the directions.

The image which can be obtained on a screen is called real image which we can see in cinema screen, not virtual screen. The image formed on cinema screen is an example of real image. A real image is formed when light rays coming from an object actually meet at a point after reflection from the mirror. A real image can be formed on a screen because light is actually passed through it.

Here, all the statements are correct. Hence your answer will be option [D].

Here, all the statements are correct. Hence your answer will be option [D].

Here, all the statements are incorrect. Hence your answer will be option [D].

We know that convex lens is used as magnifying glass in microscope, telescope etc. Convex lens is also used in spectacles to correct far sightedness. Concave lens is used in spectacles to correct short sightedness.

Here, all the statements are incorrect. Hence your answer will be option [D].

Here, all the statements are correct. Hence your answer will be option [D].

The paths of light changes when it falls on a mirror. The mirror changes the direction of light that falls on it, the image formed in a plane mirror is virtual. The image formed in a plane mirror cannot be received on a screen. We can see the image of our face in the mirror because the smooth and shiny surface of mirror produces regular reflection of light.

An erect and enlarged image can only be formed by a concave mirror and it is virtual in nature.

Here, all the statements are correct. Hence your answer will be option [D].

Here, all the statements are correct. Hence your answer will be option [D].

A concave mirror is also known as a “Converging mirror”. When the rays of light come closer after reflection, we say that the rays of light are converging. Generally, the concave mirror reflects the parallel rays of light in such a way that after reflection all the rays converge or meet at one point called “focus” in front of the mirror.

A shining steel spoon represents both, a concave mirror as well as convex mirror. The front side of a spoon is bent inward so the front side of a shining spoon represents a concave mirror. The backside of a spoon is bulging outward, so the backside of a shining spoon represents a convex mirror.

An object is placed at a large distance or it is close to the concave lens, a concave lens always forms an image which is virtual, erect and smaller than the object. Changing the position of object in front of a concave lens only changes the size of image. But in every case, the image formed by concave lens remains smaller than the object. Since, a concave lens always forms a smaller image than the object. Therefore, object always look smaller when seen through a concave lens.

We know that image formed by a plane mirror is virtual or illusion. The image seems in a plane mirror is behind the mirror. And the image in a plane mirror is of the same size as object. It is neither a smaller nor bigger than the object.

Whether an object is placed at a large distance or it is close to convex mirror, a convex mirror always forms an image which is virtual, erect and smaller than the object. The outer surface or back side of a shining steel spoons acts like a convex mirror. So, if you look into the outer side or back side of a shining steel spoon, we will see a virtual, erect in smaller image of our face. Only this happens due to bulging out structure of convex mirror.

Suppose, a beam of parallel rays of light falls on a convex mirror from the left side. We will see that after reflection from convex mirror, the parallel rays of light are spreading out. We can say that a beam of parallel light-rays diverges or spreads out after reflection from a convex mirror. Therefore, a convex mirror is known as a diverging mirror. Similarly, in the case of concave lens, when a beam of parallel rays of light falls on a concave lens from the left side. We will see that after passing through the concave lens the rays of light are diverging or spreading out. Thus, a concave lens is a diverging lens. In this respect, a concave lens is similar to a convex mirror because they diverge the light rays.

A concave lens can only from virtual, erect and diminished image of an object. As virtual and erect image formed by a convex lens is always magnified.
