#### Construction of A Line Segment of Given Length

###### We can draw a line segment of a given length in two ways:

(i) By using a ruler

(ii) By using compasses

###### Construction of a Line Segment by Using a Ruler:

Step 1: Mark a point M on the sheet of paper and place the ruler so that zero mark of the ruler coincides with the point.

Step 2: Mark a point N against the mark on the ruler which indicates 5.9 cm.

Step 3: Join points M and N by moving the tip of the pencil against the straight edge of the ruler. The line segment MN so obtained is the required line segment.

###### Construction of Line Segments by Using Compasses:

In order to construct a line segment of given length 5.3 cm (say) using compasses, we follow the following steps:

Step 1. Mark a point O (say) on the piece of paper and draw a line, say l passing through it.

Step 2. Place the metal point of the compasses at zero mark on the ruler and open out it such that the pencil point on the mark indicates the length of the line segment (5.3 cm) on the ruler.

Step 3. Keeping the opening of the compasses undisturbed, place it along the line l such that its metal end coincides with the point O.

Step 4. Make a stroke with the pencil end on the line l to cut it at M. The line segment OM so obtained is the required segment of the given length.

###### Constructions Using Ruler and Set Squares:

There are two triangular shaped instruments called set-squares in the geometrical box. These are usually made of thin transparent plastic sheet. In one, the angles are of 90°, 45°, 45° and in the other, the angles are 30°, 60°, 90°. The set-square in which the angles are of 30°, 60° and 90° is called the 30° set-square and the set-square in which the angles are of 90°, 45° and 45° is called the 45° sets-square. Two perpendicular edges in these set-squares are usually graduated, one in centimetres and the other in inches.

Set-squares are used to draw parallel and perpendicular lines. They can also be used to construct specific angles of 30°, 45°, 60° and 90°.

### Class 6 Maths Exercise 5.1 Important Extra Questions

##### What do you mean by line segment?

A line may have infinite length, a finite length on a line say AB is called line segment.

##### What is a compass in geometry?

A compass is a drawing instrument used for drawing lines, circles and arcs. It has two legs, one with a point and the other with a pencil or lead. Along with a straightedge, the compass is used extensively in constructions.

##### Why it is called Set Square?

It could also be that the “set square” normally comes from a “geometry set” (a set of rulers/tools), so it is the “set square” the “square-making tool from the set”.

##### How do you use set square tool?

It is used for marking out right angles before any joint is cut. It can also be used for marking straight lines and checking straight edges. The tool is often used alongside other tools such as the layout knife. The square and layout knife combined are regularly used to create very precise lines to cut to.
